Automatic Straight Line Folder Gluer Small Gling Machine
The machine is adopted with strengthened single-side driving system, for steady running and easy maintenance.
Product Details
ZH-780B
Folding Gluing Machine (Casting construction )
1. Features:
ZH-780B type semi-automatic sticky box machine is in recent years the carton manufacturing of new environmental protection equipment, mainly for the carton adhesion, discard the traditional copper nail binding method, improve the production efficiency, ChanPinXing good quality.
Main frame: frame, lift workstation, conveying equipment, middle recently conveying equipment, pressure and device, finished product middle side output equipment, electrical control equipment.
2. Main technical parameter:
Model | ZH-780 |
Top speed | 240m/min |
Sheet applicable | 210-800g（cardboard,E corrugated paper） |
Electric power single phase | 220V,3KW |
A side Max paper in size | 780mm |
A side Min paper in size | 350mm |
B max finished product in size | 170mm |
B min finished product in size | 50mm |
C side longest paper | 700mm |
C side shortest paper | 60mm |
D side min pasting side | 8mm |
Overall dimension | 8000*1200*1400mm |
Weight of machine | 3000kg |
Casting construction | 40mm |
Machine configuration
| Main motor | suchuang shanghai |
Bearing | made in china |
Wall thickness | 40mm Casting Construction |
Feeding belt | made in china |
Plain belt | made in china |
Low voltage apparatus | CHNT |
Fasten bolts | Level 8.8 tanwan |
