Straight Line Flexo Printing Folder Gluer Machine
There are five functions for the casting construction.
1.Operation and adjustment are characterized by fast speed.
2.High-speed production,sound stability.
Product Details
ZH-380B
Folding Gluing Machine (Casting construction )
1. Features:
There are five functions for the casting construction.
1.Operation and adjustment are characterized by fast speed.
2.High-speed production,sound stability.
3.Machine is difficult to become deformed.
4.The machine is characterized by less troubles,lower noise and long service life.(The non-standard products can be designed for customer)
5.Casting construction ,High speed running,the machine more stable.
2.Standard & Optional configuration list
Configuration | Units | Standard | Optional | |
1 | Feeder section | √ | ||
2 | Paper Alignment Section | √ | ||
3 | Pre-fold Section | √ | ||
4 | Crash lock bottom section | √ | ||
5 | Upper paste barrel equipment | √ | ||
6 | Down pasting equipment | √ | ||
7 | Gluing system | √ | ||
8 | Grinding part | √ | ||
9 | Plasma treatment system | √ | ||
10 | Folding and closing section | √ | ||
11 | Trombone section | √ | ||
12 | Air compressor | √ |
3.Main technical parameter:
Model | ZH-380 |
Top speed | 240m/min |
Sheet applicable | 210-800g |
Electric power single phase | 220V,3KW |
A side Max paper in size | 380mm |
A side Min paper in size | 70mm |
B max finished product in size | 170mm |
B min finished product in size | 30mm |
C side longest paper | 500mm |
C side shortest paper | 40mm |
D side min pasting side | 6mm |
Overall dimension | 5800*800*1300mm |
Weight of machine | 2000kg |
Casting construction | 40mm |
4.Machine configuration
| Main motor | suchuang shanghai |
Bearing | made in china |
Wall thickness | 40mm Casting Construction |
Feeding belt | made in china |
Plain belt | made in china |
Low voltage apparatus | CHNT |
Fasten bolts | Level 8.8 tanwan |
5.Feature
1.Feeder Section
Equipped with vibrating motor.
With independent transmission,low noise,with front adjustable wheels,max working capacity can be achieved.
2.Folding Section
Longer Folding section convenient adjustment and operation can fold boxes perfectly
3.Press section
Pneumatic pressure adjustment.
